GE Vivid i vs Vivid q Board Repair by Symptom

Quick Navigation

• 1. When Does FDA Language Say Vivid i, When Does It Say Vivid q, and Why Is K082374 Combined Naming Not a Leftover 2404903 Swap License?
• 2. Which Vivid i or Vivid q Board Domain Does My Symptom Point To? (Table 1: Symptom-to-Board Routing Matrix)
• 3. Why Catalog Vivid I/Q TI 5627960-2 / 5721484-2 Is Not Leftover TX64 2404903, RX64 2404906, or Probe-Interface R2360223-5
• 4. If the Laptop Dies off the Adapter, Why Is That Catalog Battery 5423275 or Inventory DC R2403248-4 on the Portable Parent Rather Than a TI Order?
• 5. When Must I Clear Z-0756-2023 or Z-0757-2023 Before Treating a Vivid i or Vivid q Power Fault as a Board or Pack RFQ?
• 6. If /models/ge-vivid-i-vivid-e and /models/ge-vivid-i-q Both Exist, Why Is That Taxonomy Plus Two Catalog Photos Rather Than Two Machines, and Why Are Vivid E95 Cases Not This Laptop?
• 7. GE Vivid i, Vivid q, and Aftermarket Part Number Collision Matrix (Table 2)
• 8. Where Vivid iq, Vivid 7, Vivid S, and Vivid E Cart Tickets Go, and Why K243620 Naming Vivid iq Is Not This Laptop's Parts List
• 9. Where Rongtao Fits, and Where It Does Not — Including Quote-Ready Photos
• 10. Frequently Asked Questions (FAQs)

When Does FDA Language Say Vivid i, When Does It Say Vivid q, and Why Is K082374 Combined Naming Not a Leftover 2404903 Swap License?

In the ultrasound parts aftermarket, independent service organizations, biomedical engineers, and equipment dealers regularly encounter sales listings that collapse distinct GE compact models into a single broad description. Part numbers are frequently advertised as fitting "GE Vivid i / Vivid e / Vivid q / LOGIQ e" simultaneously. Shared laptop form factor is not a leftover 2404903 swap license. Official FDA 510(k) premarket notification records differentiate these named devices across distinct submissions.

The original compact Vivid i was cleared under Premarket Notification K061525 (cleared 2006-07-03, Special, product code IYN, 21 CFR 892.1550, subsequent codes ITX and IYO, applicant General Electric Co.) ^{1 2}. The official FDA record explicitly specifies the device name as GE VIVID - I, preserving a distinct hyphen. Across FDA CDRH database extracts under ultrasound product codes (IYN, IYO, ITX), named laptop Vivid i submissions comprise n=5 unique 510(k) numbers: K061525, K082374, K092140, K102388, and K121062 ². These figures represent formal regulatory clearance events, not installed-base density or component failure rates.

Two years later, K082374 (cleared 2008-09-02, Traditional, primary product code IYN) introduced the Vivid q, explicitly cleared under the dual device name VIVID I AND VIVID Q ³. Subsequent filings corroborated this combined grouping: K092140 (cleared 2009-08-21, Special, IYO) named GE VIVID I DIAGNOSTIC ULTRASOUND, GE VIVID Q DIAGNOSTIC ULTRASOUND, while K102388 (cleared 2010-11-04, Special, IYN) named VIVID I DIAGNOSTIC ULTRASOUND SYSTEM ¹². Finally, K121062 (cleared 2012-08-17, Traditional, primary product code ITX, 21 CFR 892.1570, subsequent IYN/IYO/LLZ) named both VIVID I DIAGNOSTIC ULTRASOUND SYSTEM and VIVID Q DIAGNOSTIC ULTRASOUND SYSTEM ⁴. Those subsequent codes are classification, not a probe-for-TI license.

Crucially, combined regulatory naming on K082374 or K121062 does NOT establish that every internal printed circuit board is interchangeable between Vivid i and Vivid q. While both systems utilize the photo-verified front-end Vivid I/Q TI Board 5627960-2 / 5721484-2 ⁹, other subassemblies differ. For instance, legacy leftover notes document distinct probe connector boards: Vivid i uses probe interface R2360223-5 / 5393629 / KTI300740-2, whereas Vivid q documents probe interface 2379846. Furthermore, combined compact clearance K072797 (cleared 2007-10-17, Special, IYO) names GE LOGIQ I COMAPACT ULTRASOUND, GE LOGIQ E COMPACT ULTRASOUND, GE VIVID E COMPACT ULTRASOUND ⁵. Combined naming is not a pin-for-pin map onto catalog Vivid I/Q TI 5627960-2. Laptop LOGIQ e has its own photographed transmit board (LOGIQ e TX64 5436388) on the LOGIQ e family path ¹¹. Ordering leftover TX64 2404903 into a Vivid i chassis based on combined marketing names is unverified interchange.

Finally, search engine queries for compact Vivid repair frequently surface recent product pages for the Vivid iq, cleared most recently under K243620 (cleared 2025-02-11, Traditional, primary IYN, applicant GE Medical Systems Ultrasound and Primary Care Diagnostics) ⁶. Vivid iq named clearances comprise n=5 unique k_numbers from K161706 through K243620. Leftover note CPS Board 5628551 is tagged to Vivid iq, not to laptop Vivid i. Later iq naming is not an end-of-support notice for laptop Vivid i and is not a donor pool for Vivid i boards. Treat Vivid iq search results as SERP pollution and match the etched laptop suffix instead.

Which Vivid i or Vivid q Board Domain Does My Symptom Point To? (Table 1: Symptom-to-Board Routing Matrix)

Before ordering a replacement assembly or disassembling a compact console, service engineers must systematically map observed operational symptoms to functional hardware domains. Table 1 defines the differential diagnostic routing for primary failure modes encountered on GE Vivid i and Vivid q ultrasound laptops.

Why Catalog Vivid I/Q TI 5627960-2 / 5721484-2 Is Not Leftover TX64 2404903, RX64 2404906, or Probe-Interface R2360223-5

A pervasive source of confusion in the ultrasound parts marketplace is the conflation of the front-end transmit beamformer assembly. On e-commerce platforms, broker inventory feeds, and social media channels (such as Instagram parts cards), part number 2404903 is routinely marketed with broad titles such as "GE Vivid i / Vivid e / Vivid q / LOGIQ e TX64 Board P/N 2404903". This marketing shorthand treats several distinct hardware assemblies as direct drop-in equivalents.

The Rongtao Medical parts catalog photographs Vivid I/Q TI Board 5627960-2 / 5721484-2 ⁹. This snapshot has no matching inventory row for that PN. Stock turns; live availability is confirmed on the catalog or quote path. The catalog photograph shows both 5627960-2 and 5721484-2. Dual labeling is not an authorization to swap this assembly into a chassis configured for leftover TX64 2404903.

In contrast, part number 2404903 (and its commercial revisions 2404903-2, 2404903-3, and 2404903-7) represents a legacy leftover component. As thoroughly established on the GE LOGIQ e Decision Path, part number 2404903 is actively sold in the aftermarket as a LOGIQ e transmit board, where it collides with the photo-verified catalog SKU LOGIQ e TX64 5436388 ¹¹. This article owns the Vivid i destination of that leftover: legacy product notes in the repository archive (repair-ge-vivid-i-vivid-e-vivid-q-tx64-board-p-n-2404903) tag 2404903 with compact Vivid models ¹¹. However, leftover tagging does not make 2404903 identical to catalog TI 5627960-2. Swapping a board solely on leftover title tagging is unverified interchange.

Furthermore, clinical engineers must distinguish the transmit TI board from adjacent leftover titles: RX64 Receive Board 2404906, leftover TR32 boards 2354258-6 / 2354258-7 / R2354258-12, Back-End Processor (BEP) R2380485 / R2356466, RFI shielding board R2418295-2, and probe interface boards R2360223-5 / 5393629 / KTI300740-2 (Vivid i leftover tagging) and 2379846 (Vivid q leftover tagging). None of these assemblies are catalog photo SKUs, and none are a substitute for catalog TI 5627960-2. When front-end acoustic faults occur, match the etched part number and revision suffix before requesting a replacement.

If the Laptop Dies off the Adapter, Why Is That Catalog Battery 5423275 or Inventory DC R2403248-4 on the Portable Parent Rather Than a TI Order?

A frequent diagnostic error in field servicing occurs when an untethered power failure is mistaken for a front-end system fault. When a Vivid i or Vivid q console powers on cleanly while connected to its external medical-grade AC adapter, executes self-tests, and scans without error, but shuts down instantaneously the moment the AC plug is pulled, the acquisition beamformer (TI board) is completely intact. The fault resides entirely within the portable DC power distribution and energy storage subsystem.

The compact Vivid laptop power path has three stages that must be matched separately: the external medical AC adapter, the internal DC/DC distribution board, and the internal lithium-ion pack. Untethered shutdown with a working adapter is not a TI-board ticket.

The photographed catalog SKU for internal energy storage on this platform is Vivid i/e Battery 5423275 / 5401269 ¹⁰. This snapshot has no matching inventory row for that PN. Adjacent inventory leftover is Vivid I DC/DC R2403248-4, which carries a 90-day warranty field. Tickets involving untethered shutdown, battery failure to charge, or DC distribution belong on the dedicated portable battery and DC power path.

Biomedical teams must avoid several aftermarket traps. Catalog battery 5423275 is not a shopping leftover suffix or an S-series cart pack; those collisions belong on the portable battery parent and the Vivid S-series path after matching. Inventory leftover DC/DC R2403248-4 is distinct from leftover DC boards 5439596 / 5396104 and leftover LOGIQ e DC boards 2403248-2 / 2408403-2. Disassembling a console to replace the front-end TI board when the system simply will not hold charge off the adapter wastes budget and is the wrong family ticket.

When Must I Clear Z-0756-2023 or Z-0757-2023 Before Treating a Vivid i or Vivid q Power Fault as a Board or Pack RFQ?

Before treating an untethered power fault as a DC/DC or pack RFQ, clinical engineering departments should check the equipment against current regulatory safety notices. The FDA Medical Device Recalls database records a Class II action on the compact Vivid battery subsystem.

Under FDA Recall Z-0756-2023 (recall event ID 91139, initiated 2022-11-10, posted 2022-12-22, product code ITX, Open/Classified on the Class 2 page and Class II Ongoing on openFDA enforcement last_updated 2026-09-09), the recalling firm is GE Medical Systems, LLC and the listed product is Vivid i ultrasound ⁷. Sibling Class II recall Z-0757-2023 covers Vivid q (res.cfm?id=197026). Additional designations Z-0758-2023 and Z-0759-2023 apply to Vivid i N and Vivid q N configurations not marketed in the United States.

The official manufacturer reason is that batteries that have not been replaced at 2 years, as recommended in the Service Manual, can fail or possibly emit smoke or catch fire ⁷. Firm action is to replace the battery every 2 years or if the battery is not capable of powering the system for more than 30 minutes.

From an evidence-based servicing perspective, several boundaries must be strictly observed. First, Quantity in Commerce on the Class 2 page is recall scope, not the number of battery thermal incidents. It is not republished here. Second, openFDA Manufacturer and User Facility Device Experience (MAUDE) queries using quoted part numbers (5423275, 5401269, 5627960-2) returned zero matching adverse event reports (NOT_FOUND) as of last_updated 2026-09-08 ⁸. Passive surveillance data does not establish failure incidence, and quoted database emptiness must not be misconstrued as proof that batteries never fail. Finally, the recall 510(K)Number field lists K033139, K061525, K082374, K092140, and K102388; the product text also names K121062. K033139 on that list is an associated clearance, not a Vivid i SKU identity. Clearing the 2-year replacement interval and the 30-minute runtime test is a safety prerequisite before ordering power assemblies.

If /models/ge-vivid-i-vivid-e and /models/ge-vivid-i-q Both Exist, Why Is That Taxonomy Plus Two Catalog Photos Rather Than Two Machines, and Why Are Vivid E95 Cases Not This Laptop?

Rongtao publishes two model URLs for this compact family: /models/ge-vivid-i-vivid-e and /models/ge-vivid-i-q. Those routes are catalog taxonomy, not proof of two machines.

Catalog battery 5423275 is indexed under the model string VIVID I VIVID E, which produces /models/ge-vivid-i-vivid-e. Catalog TI 5627960-2 is indexed under VIVID I/Q, which produces /models/ge-vivid-i-q. Both pages exist so those two photographed SKUs can be browsed. They are not evidence that GE sold separate console lines called "Vivid I Vivid E" and "Vivid I/Q".

A more serious trap sits on /models/ge-vivid-i-vivid-e: the page currently lists cart Vivid E95 repair cases from the service archive. Those cases share a Vivid E model token with the compact catalog string VIVID I VIVID E. Clinical engineers must treat that as taxonomy error. Cart E95 belongs on the Vivid E9/E80/E90/E95 cart path, not as laptop Vivid i proof.

Ground truth in documented service records confirms that Rongtao maintains zero photo-documented teardown cases for laptop Vivid i boards. Service providers must never invent bench repair statistics or cite cart Vivid E95 case studies as evidence of laptop Vivid i servicing capabilities. In our documented service coverage scope, GE coverage explicitly includes "Vivid I/E" alongside Voluson, Logiq, Vivid E cart, Vivid S, and Versana Balance. Rongtao supports compact Vivid board diagnosis, testing, and component-level repair, but coverage must never be exaggerated to imply support for unlisted platforms such as Vivid iq, console Vivid 7, Vivid Pioneer, or Marlin.

GE Vivid i, Vivid q, and Aftermarket Part Number Collision Matrix (Table 2)

Table 2 provides an exhaustive cross-reference of part numbers, board markings, catalog statuses, and collision risks encountered when sourcing replacement assemblies for GE Vivid i and Vivid q ultrasound systems.

Where Vivid iq, Vivid 7, Vivid S, and Vivid E Cart Tickets Go, and Why K243620 Naming Vivid iq Is Not This Laptop's Parts List

To maintain high diagnostic accuracy and avoid sending biomedical engineers down irrelevant troubleshooting paths, service inquiries that do not match the laptop Vivid i or Vivid q architecture must be systematically routed to their proper parent articles or specialized family paths:

Vivid iq Tickets: Clearances such as K243620 (2025-02-11 Traditional, IYN) name the Vivid iq, which is a different named device from laptop Vivid i ⁶. Leftover CPS Board 5628551 is tagged to Vivid iq and is a leave-this-page identity. Vivid iq inquiries are not this laptop's parts list.

Console Vivid 7 Tickets: Search queries for Vivid i board repair frequently return leftover notes for cart-based Vivid 7 (ge-vivid-7-failure-to-boot-troubleshooting), which ranks on the family-repair SERP ¹¹. Named Vivid 7 unique 510(k) numbers in the same extract are n=5 from K003931 through K060542. That generation is not this laptop. Tickets involving Vivid 7 boot failures must leave this page.

Vivid S-Series Cart Systems: Inquiries involving the Vivid S5, Vivid S6, Vivid S60, or Vivid S70 must be routed to the GE Vivid S-Series Decision Path. S-series leftover battery tagging such as S5399340-4 is not catalog 5423275. Regulatory notices that apply to those carts belong on that family path, not as this laptop's battery gate.

Vivid E-Series Premium Carts: Faults on full-sized cardiovascular cart systems—including the Vivid E9, Vivid E80, Vivid E90, and Vivid E95—belong on the GE Vivid E9/E80/E90/E95 Cart Decision Path. As noted, cases from this cart family attached to `/models/ge-vivid-i-vivid-e` must not be treated as laptop repair evidence.

LOGIQ e Sibling Compacts: If the equipment is a general-imaging LOGIQ e laptop, or if the inquiry involves isolating leftover 2404903 against verified catalog SKU 5436388, route directly to the GE LOGIQ e Decision Path.

Component-Level Physics Parents: For consoles confirmed to be laptop Vivid i or Vivid q systems, route specific failure modes to established component parents after matching part numbers: channel dropouts after known-good probe testing route to the beamformer front-end failure parent; boot freezes at the splash screen route to the host/HDD boot failure parent; back-end digital video artifacts route to the backend image processing parent; battery charging and untethered DC rail faults route to the portable battery and DC power parent; and general GE platform inquiries route to the GE ultrasound board symptoms hub.

Where Rongtao Fits, and Where It Does Not — Including Quote-Ready Photos

To ensure transparent B2B collaboration with clinical engineering teams, independent service organizations, and medical equipment distributors, Rongtao Medical clearly defines its service capabilities and operational boundaries for GE Vivid i and Vivid q ultrasound equipment:

Where Rongtao Fits:

• Component-level board repair: Photographed compact Vivid assemblies such as Vivid I/Q TI Board 5627960-2 / 5721484-2 after the etched suffix is matched, plus inventory leftover Vivid I DC/DC R2403248-4 after matching.
• 48-hour real-machine testing: Every serviced board runs inside an actual ultrasound before release, not bench-only.
• Standard commercial terms: Typical board-repair turnaround is 5 to 8 business days upon receipt, with a typically 90-day warranty, confirmed per item at quote. Facilities operate under ISO 13485:2016 and ISO 9001:2015 quality management systems.
• Tested replacement modules: Photo-inspected, tested replacement assemblies when repair of the customer's board is not feasible.

Where Rongtao Does NOT Fit:

• No DIY repair instructions: We do not provide DIY guides or circuit-bypass instructions for untrained personnel to work on energized equipment.
• No OEM authorization claims: Rongtao Medical is an independent service organization and parts supplier. We do not claim to be an authorized representative of GE HealthCare. OEM trademarks identify equipment compatibility only.
• No remote certainty without inspection: We do not guarantee repairability or part compatibility without photos of the board label, part-number suffix, and fault symptoms.
• No unverified generic batteries as catalog identity: Shopping suffix 5792236 and empty-cover / S-series pack collisions belong on the portable battery parent after matching, not as silent swaps for catalog 5423275.

Quote-Ready Information Checklist: To receive an actionable, binding quotation for GE Vivid i or Vivid q board repair or tested replacement, clinical engineers should submit the following details via our contact and quotation portal:

1. Console Model & Revision: Exact model name from the rear rating plate (e.g., Vivid i vs Vivid q vs Vivid e compact).
2. Part Number & Suffix: Full part number and revision suffix etched on the PCB silk screen or printed on the barcode label (e.g., 5627960-2, 5423275, R2403248-4).
3. Photographic Documentation: Clear, well-lit, high-resolution photographs of BOTH sides of the board or battery pack, clearly showing barcode labels, silk-screen revisions, and connector pins.
4. Detailed Failure Description: Specific operational symptoms, exact on-screen error messages, and whether a known-good probe or labeled pack was already tried.
5. Quantity & Shipping Destination: Required service quantity and destination country / postal code for accurate freight and customs estimation.

Frequently Asked Questions (FAQs)

Is leftover 2404903 the same board as catalog Vivid I/Q TI 5627960-2?
No. Part number 2404903 is a leftover title commonly advertised across multiple GE compact systems, including LOGIQ e. The photographed catalog SKU for the Vivid i and Vivid q front-end is Vivid I/Q TI Board 5627960-2 / 5721484-2. Swapping 2404903 into a Vivid i chassis based solely on leftover e-commerce titles is unverified interchange.

Does K082374 naming Vivid i and Vivid q together mean I can swap a Vivid q leftover into a Vivid i chassis?
No. FDA Premarket Notification K082374 cleared both systems under a shared regulatory submission, establishing platform commonality. However, regulatory clearance does not guarantee pin-for-pin hardware interchangeability across all subassemblies. For instance, probe interface board part numbers differ between Vivid i (R2360223-5) and Vivid q (2379846). Part numbers must be verified against physical labels before swapping.

Is Vivid iq the same machine as Vivid i, and does K243620 from 2025-02-11 make this an end-of-support playbook?
No. The Vivid iq (K243620) is a different named device. Leftover CPS Board 5628551 is tagged to Vivid iq, not to laptop Vivid i. Later iq clearance is not an end-of-support timestamp for laptop Vivid i.

My search result mixed Vivid i with LOGIQ e TX64 2404903-3. Which family path owns that leftover?
Part number 2404903 is the other half of the compact beamformer split. The LOGIQ e Decision Path owns the LOGIQ e destination of leftover 2404903, isolating it from catalog LOGIQ e TX64 5436388. This article owns the compact Vivid destination of that leftover, isolating it from catalog Vivid I/Q TI 5627960-2.

The console runs on the adapter but dies immediately when unplugged. Is that TI 5627960-2 or battery 5423275?
Untethered shutdown isolates to the power subsystem, specifically Vivid i/e Battery 5423275 / 5401269 or internal DC/DC power distribution. The front-end TI board 5627960-2 is completely uninvolved in untethered power holding. Route this failure to the portable battery parent and verify the pack against FDA Recall Z-0756-2023.

Can I follow iFixit, JustAnswer, or Avante Vivid-and-LOGIQ-E9 tips to open this laptop myself?
No. Ultrasound laptops contain high-energy transmit circuitry and ESD-sensitive assemblies. Generic DIY wiki guides or forum tips are not a qualified-service procedure. Disassembly and repair belong with qualified biomedical service engineers using calibrated test fixtures.
